2011 JLG G10-55A
Dimensions A. Length to Fork Face20 ft in6090 mm B. Width Over Tires8.4 ft in2560 mm C. Overall Height8.4 ft in2560 mm D. Wheelbase12 ft in3650 mm E. Ground Clearance18 ft in457 mm Lift F. Max Lift Height55.1 ft in16800 mm G. Max Forward Reach42 ft in12800 mm Specification Engine Make2240 Modele 4045TF275 Gross Power124.7 hp93 kw Displacement274.6 cu in4.5 L Aspirationturbocharged Operational Operating Weight34400 lb15603.6 kg Fuel Capacity38 gal144 L Hydraulic System Fluid Capacity57 gal215.7 L Operating Voltage12 V Alternator Supplied Amperage65 amps Drawbar Pull20000 lb9071.8 kg Tire Size14.00x24 12PR Transmission TypeZF WG98 powershift Number of Forward Gears4 Number of Reverse Gears3 Max Speed - forward19.9 mph32 km/h Hydraulic Pump Typeload sensing piston pump Lift Max Lift Capacity10000 lb4535.9 kg Max Lift Height55.1 ft in16800 mm Max Load at Max Height5000 lb2268 kg Max Forward Reach42 ft in12800 mm Max Load at Max Reach3000 lb1360.8 kg Dimensions Length to Fork Face20 ft in6090 mm Width Over Tires8.4 ft in2560 mm Overall Height8.4 ft in2560 mm Wheelbase12 ft in3650 mm Ground Clearance18 ft in457 mm Turning Radius Outside Tires14 ft in4270 mm Thank you for expressing interest in a piece of equipment from Coast to Coast Equipment! For the last 14 years, we have been providing top notch service and products to our partners in profit. Our experienced sales and procurement team have the ability to find you exactly what you need. Our machines all have annual inspections so you can be assured of the quality of your purchase. Every single piece of equipment you receive from us will be in job site ready/rental ready condition. As soon as it is off loaded you can put it right to work! We stand behind every single piece of equipment that we sell and our reps understand that you and your best interest are our top priority. Machines in our yard are delivered in job ready condition, which includes: • All of the fluids are regularly maintained • Chains and wear pad adjustments • Operational horn and backup alarm • Good service and parking brake • Good charging and exhaust systems • Frame and boom inspected for bends, cracks and welds We stand behind our products all of our machines have current ANSI certifications. We invite all of our customers to come to Ohio and inspect our machines before buying from us.Seller Name: Jim HallPhone Number: +13304627045Location: Cleveland, Ohio 44105Product Year: 2011Product Manufacturer: jlgProduct Stock Number: T10K#022Product Operating Condition: OperableProduct Hours: 9846Product Condition: Used
Contact Seller
Seller Company:Seller Name: Jim Hall
Login To Contact Seller
Apply for Financing
First Citizens Bank is our partner for your financing needs. Contact our representative below:Apply For Financing Now
Product Title
:
Product Id
:
Product Code
:
2011-JLG-G10-55A
Description
:
Dimensions
A. Length to Fork Face20 ft in6090 mm
B. Width Over Tires8.4 ft in2560 mm
C. Overall Height8.4 ft in2560 mm
D. Wheelbase12 ft in3650 mm
E. Ground Clearance18 ft in457 mm
Lift
F. Max Lift Height55.1 ft in16800 mm
G. Max Forward Reach42 ft in12800 mm
Specification
Engine
Make2240
Modele 4045TF275
Gross Power124.7 hp93 kw
Displacement274.6 cu in4.5 L
Aspirationturbocharged
Operational
Operating Weight34400 lb15603.6 kg
Fuel Capacity38 gal144 L
Hydraulic System Fluid Capacity57 gal215.7 L
Operating Voltage12 V
Alternator Supplied Amperage65 amps
Drawbar Pull20000 lb9071.8 kg
Tire Size14.00x24 12PR
Transmission
TypeZF WG98 powershift
Number of Forward Gears4
Number of Reverse Gears3
Max Speed - forward19.9 mph32 km/h
Hydraulic
Pump Typeload sensing piston pump
Lift
Max Lift Capacity10000 lb4535.9 kg
Max Lift Height55.1 ft in16800 mm
Max Load at Max Height5000 lb2268 kg
Max Forward Reach42 ft in12800 mm
Max Load at Max Reach3000 lb1360.8 kg
Dimensions
Length to Fork Face20 ft in6090 mm
Width Over Tires8.4 ft in2560 mm
Overall Height8.4 ft in2560 mm
Wheelbase12 ft in3650 mm
Ground Clearance18 ft in457 mm
Turning Radius Outside Tires14 ft in4270 mm
Thank you for expressing interest in a piece of equipment from Coast to Coast Equipment! For the last 14 years, we have been providing top notch service and products to our partners in profit. Our experienced sales and procurement team have the ability to find you exactly what you need. Our machines all have annual inspections so you can be assured of the quality of your purchase. Every single piece of equipment you receive from us will be in job site ready/rental ready condition. As soon as it is off loaded you can put it right to work! We stand behind every single piece of equipment that we sell and our reps understand that you and your best interest are our top priority. Machines in our yard are delivered in job ready condition, which includes:
• All of the fluids are regularly maintained
• Chains and wear pad adjustments
• Operational horn and backup alarm
• Good service and parking brake
• Good charging and exhaust systems
• Frame and boom inspected for bends, cracks and welds
We stand behind our products all of our machines have current ANSI certifications. We invite all of our customers to come to Ohio and inspect our machines before buying from us. Seller Name: Jim Hall Phone Number: +13304627045 Location: Cleveland, Ohio 44105 Product Year: 2011 Product Manufacturer: jlg Product Stock Number: T10K#022 Product Operating Condition: Operable Product Hours: 9846 Product Condition: Used
